380V Industrial Mig Welding Machine Mig-500 Double Pulse Water Cooling Synergic System

Description：

1.3-phase 380V, 50/60Hz; Multi-voltage optional (3-phase 220V/380V/440V), ideal for complex power grids

2.Professional MIG welding machine featured with IGBT module, separate wire feeder . water cooling and digital signal processing, supporting single pulse, double pulse and intelligent synergic control

3.Save & load up to 20 welding programs.You can preset and store optimal parameters for different workpieces, materials and welding tasks, realize one-click quick recall without repeated adjustment, which guarantees stable and consistent welding quality, saves tedious setup time and improves overall welding efficiency significantly.

4.5 programs accessible via torch trigger; Separate wire feeder applicable for 20kg wire spool

5.Flexible remote welding available; Versatile welding processes optional: MIG, MAG, MIG Synergy, MIG Single Pulse, MIG Double Pulse, High-speed MIG Single Pulse, High-speed MIG Double Pulse, TIG, Spot Welding, MMA

6.Compatible with 9-axis robotic arm welding requirements, featuring high-precision welding control and stable signal transmission, perfectly meeting  the demand for automated and large-scale welding production.

7.Energy-saving & high-efficiency (efficiency increased by 35%)

8.Wide material compatibility: FeC, ER316, ER308, ER304, Galvanized steel sheet,pure aluminum, aluminum alloys, AlSi5(4043) , AlMg5(5356) , CuSi3, etc.

9.Applicable wire diameter: 0.8-1.6mm. Compatible with various welding electrodes.

10.High-capacity water tank and powerful pump for optimal cooling performance .

11.Multiple functions & protections: VRD, 2T/4T, Special 4T, welding thickness selection, inductance adjustment, hot start, arc force, burn back,pre-gas/post gas setting, over current protection, over voltage protection, thermal protection, phase loss protection.gas checking , wire checking .

12.Equipped with 4-roll wire drive for smooth wire feeding, delivering fast dynamic response,

13.Rugged & robust structure.Trolley-mounted with movable wheels for easy mobility

14.Deep penetration and excellent welding performance. smooth and neat weld seams, along with high strength and outstanding durability. Ideal for high-demand, quality-focused welding applications especially in heavy industry

15.The machine comes with a complete set of accessories including:

• MIG torch +cable 3m ,installed stl liner 1,2-1,6mm
• electrode holder ,2 m
• earth clamp  3m
• Interconnection power cable ,5 m
• 7-pin control cable 5m
• water pipe 5m
• gas hose 6.5m
• steel liner
• Telflon liner
• contact tips of steel welding
• contact tips of alum welding
• V-roller
• U-roller

Specifications：

Applications:

Equipped with graded high output and reliable load capacity, these industrial MIG welders excel in diverse heavy-duty industrial welding, widely applied to light/medium/heavy steel structures, construction steel components, heavy machinery parts, containers, sheet metal, pipelines, shipbuilding (auxiliary structures & hull segments), bridges, high-rises, thick-wall pipelines and metallurgical equipment. Ideal for medium-to-thick/thick carbon steel and low alloy steel, they deliver stable, efficient welding with excellent penetration to meet high standards of semi-industrial, mainstream and heavy industries.
